APO cxr
Text
What radiographic features on plain X-ray are suggestive of pulmonary intistitial oedema?
- {{c1::Peribronchial cuffing}}
- {{c1::Septal (Kerley) lines}}
- {{c1::Thickening of interlobar fissures}}
- {{c1::Peribronchial cuffing}}
- {{c1::Septal (Kerley) lines}}
- {{c1::Thickening of interlobar fissures}}
Text
What <u>radiographic features</u> on <b>plain X-ray</b> are <i>suggestive</i> of <b>pulmonary <i>intistitial</i> oedema</b>?<br><br>- {{c1::Peribronchial cuffing}}<br>- {{c1::Septal (Kerley) lines}}<br>- {{c1::Thickening of interlobar fissures}}
Extra
Peribronchial cuffing (doughnut sign): Increased density around the walls of a bronchus or large bronchiole seen end-on, both on plain radiographs and on CT.
Kerley C lines: Expansion of the interstitial space by fluid.
Thickening of interlobar fissures: Fluid between the lobes of the lung
Extra
<style>
/* Container styling */
.container {
display: flex; /* Flexbox for side-by-side columns */
}
/* Column styling */
.column {
width: 33.333%; /* Each column takes up 50% of the container width */
padding: 1%;
border: 1px solid #;
background-color: ;
box-sizing: border-box; /* Ensure padding and borders don't affect width */
font-size: 10px;
}
</style>
<div class="container">
<div class="column">
<img src="edb32f699014f1f0e319ba7ab531d03a.webp">
<p><b>Peribronchial cuffing</b> (doughnut sign)<b>:</b> Increased density around the walls of a bronchus or large bronchiole seen end-on, both on plain radiographs and on CT.</p>
</div>
<div class="column">
<img src="70a77066411da78c9b2721f48d24220a.webp">
<p>
<b>Kerley </b><b>C lines:</b> Expansion of the interstitial space by fluid.</p>
</div>
<div class="column">
<img src="9d65285b37fb79b74725df56efb0891a.webp">
<p><b>Thickening of interlobar fissures:</b> Fluid between the lobes of the lung
</p>
</div>
</div>
Extra (Synced)
Empty field
Extra (Synced)
Personal Notes
Empty field
Personal Notes
Missed Questions
Empty field
Missed Questions
eTG Complete
Empty field
eTG Complete
Talley & O'Connor
Empty field
Talley & O'Connor
Additional Resources
Empty field
Additional Resources
Additional Resources (Synced)
Empty field
Additional Resources (Synced)
Source
Radiopaedia - https://radiopaedia.org/articles/pulmonary-oedema?lang=gb - Accessed 5 November 2024
Source
Radiopaedia - <a href="https://radiopaedia.org/articles/pulmonary-oedema?lang=gb">https://radiopaedia.org/articles/pulmonary-oedema?lang=gb</a> - Accessed 5 November 2024<br>
One by one
Empty field
One by one
Tags
#Malleus_CM::#Subjects::Respiratory_Medicine::05_Lungs::Acute_Pulmonary_Oedema::08_Diagnosis/Investigations
#Malleus_CM::#Resources_by_Rotation::Emergency
#Malleus_CM::#Resources_by_Rotation::Internal_Medicine::Respiratory_Medicine
